7.5kw Oilless Oil-Free Scroll Air Compressor
- FOB Price
US $5000.01 - 10 piece
US $4000.011 - 20 piece
US $3000.021 - 50 piece
- group name
- Scroll screw air compressor
- Min Order
- 1 piece
- brand name
- Jinjing Professional Air Compressor Manufacturer
- model
- SS
- Nearest port for product export
- Tianjin, Shanghai, Dalian
- Delivery clauses under the trade mode
- FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES
- Acceptable payment methods
- T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Westem Union, Cash
- update time
- Thu, 21 Nov 2024 20:01:20 GMT
Paramtents
Power 2.2-37 Kw
Displacement 0.25-4 M3/Min
OEM Accept
Packging & Delivery
-
Min Order1 piece
Briefing
7.5kw Scroll Air Compressor 5HP Oilless Air Compressor Oil-Free Scroll Air Compressor
Detailed
Advantage
1. High-quality oil-free compressed air.
2. High-efficiency oil-free scroll airend.
3. Low Energy Consumption, Low running, maintenance cost.
4. Aptitude and intelligent Control, integrated touch-screen PLC displayer.
5. Unique safe units make the whole compressor safer, and more stable,lest noise, less energy Loss.
6. Easy to install, operate, and maintain.Scroll Air Compressor
High-quality oil fee compressed air:
A high-quality 74 Degree taper connection is used to make a more reliable seal reducing the risk of air leakage. SCR's oil-free scroll machine provides 100% oil-free air and makes use of fully stainless steel pipework eliminating any possible contamination.
High-Efficiency oil-free scroll airend:
The compression chamber and lubricant system are 100% separated meaning there is no risk of oil-contaminated air.
High Reliability:
The SS range uses low noise, high-pressure centrifugal fans which provide excellent airflow. The oversized cooler has a spare capacity of between 20%-30% making the air outlet temperature only +10-15 degrees above the ambient temperature. This reduces the burden of downstream equipment.
A high-quality 74 Degree taper connection is used to make a more reliable seal reducing the risk of air leakage. SCR's oil-free scroll machine provides 100% oil-free air and makes use of fully stainless steel pipework eliminating any possible contamination.
High-Efficiency oil-free scroll airend:
The compression chamber and lubricant system are 100% separated meaning there is no risk of oil-contaminated air.
High Reliability:
The SS range uses low noise, high-pressure centrifugal fans which provide excellent airflow. The oversized cooler has a spare capacity of between 20%-30% making the air outlet temperature only +10-15 degrees above the ambient temperature. This reduces the burden of downstream equipment.
| Model | Pressure (mpa) | Displacement (m³/min) | Power (kw) | No Of Air End | Dimension (mm) | Weight (kg) | Outlet Size |
| SS-0.75/2.2 | 0.75 | 0.25 | 2.2 | 1 | 840*780*1066 | 230 | Rc1/2" |
| SS-0.85/2.2 | 0.85 | 0.24 | Rc1/2" | ||||
| SS-1.05/2.2 | 1.05 | 0.22 | Rc1/2" | ||||
| SS-0.75/3.7 | 0.75 | 0.40 | 3.7 | 1 | 840*780*1066 | 230 | Rc1/2" |
| SS-0.85/3.7 | 0.85 | 0.39 | Rc1/2" | ||||
| SS-1.05/3.7 | 1.05 | 0.37 | Rc1/2" | ||||
| SS-0.75/5.5 | 0.75 | 0.51 | 5.5 | 2 | 930*1200*1230 | 360 | Rc1" |
| SS-0.85/5.5 | 0.85 | 0.48 | Rc1" | ||||
| SS-1.05/5.5 | 1.05 | 0.44 | Rc1" | ||||
| SS-0.75/7.5 | 0.75 | 0.80 | 7.5 | 2 | 930*1200*1230 | 360 | Rc1" |
| SS-0.85/7.5 | 0.85 | 0.78 | Rc1" | ||||
| SS-1.05/7.5 | 1.05 | 0.74 | Rc1" | ||||
| SS-0.75/11 | 0.75 | 1.20 | 11 | 3 | 1400*910*1320 | 500 | Rc1" |
| SS-0.85/11 | 0.85 | 1.17 | Rc1" | ||||
| SS-1.05/11 | 1.05 | 1.11 | Rc1" | ||||
| SS-0.75/15 | 0.75 | 1.60 | 15 | 4 | 1930*1270*1340 | 720 | Rc1" |
| SS-0.85/15 | 0.85 | 1.56 | Rc1" | ||||
| SS-1.05/15 | 1.05 | 1.47 | Rc1" | ||||
| SS-0.75/18.5 | 0.75 | 2.00 | 18.5 | 5 | 1930*1270*1340 | 860 | Rc1" |
| SS-0.85/18.5 | 0.85 | 1.95 | Rc1" | ||||
| SS-1.05/18.5 | 1.05 | 1.84 | Rc1" | ||||
| SS-0.75/22 | 0.75 | 2.40 | 22 | 6 | 1930*1270*1340 | 900 | Rc1" |
| SS-0.85/22 | 0.85 | 2.34 | Rc1" | ||||
| SS-1.05/22 | 1.05 | 2.21 | Rc1" | ||||
| SS-0.75/30 | 0.75 | 3.20 | 30 | 8 | 2030*1260*2100 | 1200 | Rc1-1/4" |
| SS-0.85/30 | 0.85 | 3.12 | Rc1-1/4" | ||||
| SS-1.05/30 | 1.05 | 2.95 | Rc1-1/4" | ||||
| SS-0.75/37 | 0.75 | 4.00 | 37 | 10 | 2030*1260*2100 | 1420 | Rc1-1/2" |
| SS-0.85/37 | 0.85 | 3.89 | Rc1-1/2" | ||||
| SS-1.05/37 | 1.05 | 3.68 | Rc1-1/2" |
